Changes from revision 1.6 to revision 1.7
Changes from revision 1.7 to revision 1.8
Page Name of section / command Change
26 chapter 2.2.2 "Software" Added: Notes on new drivers
54 chapter 4.4.8 "Analog Inputs" Added.
57 chapter 5.3 "Installing the Drivers" Added: Installation under WINDOWS 8 and new section
"Software Driver Upgrade"
130 chapter 7.4.2 "Configuring the Laser
Connector (LASER)"
Added.
138 chapter 7.4.8 "Pulse Picking Laser
Mode"
Added: constant pulse length mode
149 chapter 7.4.10 "Output
Synchronization"
Added.
165 chapter 8.3 "Online Positioning" Added: matrix operation (set_mcbsp_matrix,
set_mcbsp_matrix_list)
187 chapter 8.7.6 "Virtual Image Field" Added: Examples of using the virtual image field with
Processing-on-the-fly applications
191 chapter 8.7.10 "Tracking Error
Compensation of Encoder Values for
Processing-on-the-fly Applications"
Added.
236 auto_cal command Change with version DLL 535: return value 8
242 config_laser_signals command Added (with version DLL 533, OUT 534, RBF 524)
263 get_error command Added with version DLL 535: bits #11, 12, 16
267 get_hex_version command Change with version DLL 535
277 get_rtc_version command Change with version DLL 535
311 laser_on_list command Corrected: changed behavior as of DLL 530, OUT 531,
RBF 522 (as with laser_on_pulses_list)
428 set_fly_tracking_error command Added with version DLL 533, OUT 534, RBF 524
440 set_laser_control command Added: bit#6 for output synchronization and bit#7 for
constant pulse length mode (with version DLL 530,
OUT 531, RBF 522 and DLL 533, OUT 534, RBF 524)
451 set_mcbsp_freq command Corrected: behavior for out-of-range parameter values
454 set_mcbsp_matrix command,
set_mcbsp_matrix_list command
Added with version DLL 533, OUT 534, RBF 524
470 set_pulse_picking_length
command
Added (with version DLL 533, OUT 534, RBF 524)
499 set_verify command Added with version DLL 535: automatic error recognition of
a failed memory request
523 stop_execution command Change with version OUT 535
