Commissioning and Diagnostics
6-10
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
6.1.2 Commissioning and startup of the ET 200S on PROFIBUS DP
Software requirement NONE
Table 6-3 Software requirements for commissioning on PROFIBUS DP
Engineering software
used
Version Notes
STEP 7 As of Version 5.0
and ServicePack 3
You are using HW Config. As of ServicePack 3 the
ET 200S is included in the hardware catalog.
COM PROFIBUS As of Version 5.1,
ServicePack 2,
Hotfix 1
You have integrated the device database file of ET 200S
in COM PROFIBUS.
Configuration software
for a different DP
master
You need the device database file of ET 200S.
Requirements for commissioning the ET 200S
Table 6-4 Requirements for commissioning the ET 200S on PROFIBUS DP
Prior Activity
See ...
1. DP slave installed Chapter 4
2. PROFIBUS address set on the DP slave Section 4.8
3. DP slave wired Chapter 5
4. DP slave configured (configured and parameters assigned) Section 6.1.1
5. Supply voltage switched on for DP master DP master manual
6. DP master set to RUN mode DP master manual
Commissioning the ET 200S
Table 6-5 Procedure for commissioning the DP slave
Step
Procedure See .
1. Switch on the supply voltage for the DP slave. Section 8.2
2. Switch on the supply voltage for the load as necessary.
