Siemens SIMATIC ET 200S - Terminal Assignment of the 4 DI 24 VUC High Feature

Digital Electronic Modules
11-29
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
Terminal assignment
The following table shows the terminal assignment of the 4DI 24--48 VUC High
Feature for the various terminal modules:
Table 11-9 Terminal assignment of the 4DI 24 VUC High Feature
View
Terminal assignment Remarks
AUX1 (PE)
2
3
4
6
7
8
1
5
DI
1
DI
0
24/48 VAC/VDC
2-wire 3-wire
TM-E15S24-A1 and
4DI 24--48 VUC High Feature
CH1
CH3
CH0
CH2
DI
2
DI
3
24/48 VAC/VDC
AUX1 (PE)
AA
Channel 0:
terminals 1 and 3
Channel 1:
terminals 5 and 7
Channel 2.
terminals 2 and 3
Channel 3:
terminals 6 and 7
DI: Input signal
24 V DC sensor power
supply
PE: Chassis ground
2
3
4
6
7
8
1
5
2-wire
TM-E15S24-01 and
4DI 24--48 VUC High Feature
CH1
CH3
CH0
CH2
DI
1
DI
0
DI
2
DI
3
24/48 VAC/VDC
24/48 VAC/VDC
24/48 VAC/VDC
24/48 VAC/VDC
Channel 0:
terminals 1 and 3
Channel 1:
terminals 5 and 7
Channel 2:
terminals 2 and 4
Channel 3:
terminals 6 and 8
DI: Input signal
24 V DC sensor power
supply
