General Technical Specifications
7-8
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
7.3 Mechanical and climatic environmental conditions
Climatic environmental conditions
The following climatic environmental conditions apply:
Environmental conditions Operating ranges Remarks
Temperature
from0to60_C For horizontal installation
from0to40_C For all other mounting positions
From0to55_C
(see restrictions below)*
For vertical installation
Temperature change 10 K/h
Relative humidity From 15 % to maximum 95 % Without condensation
Air pressure From 1080 hPa to 795 hPa Corresponds to an altitude of
--1000 m to 2000 m
Contaminant concentration
SO
2
: < 0.5 ppm;
rel. humidity < 60 %, no dewing
H
2
S: < 0.1 ppm;
rel. humidity < 60 %, no dewing
Test:
10 ppm; 4 days
1 ppm; 4 days
* Restrictions for the operating range of 0 to 55
_C in a vertical position
The operating range of 0 to 55_C in a vertical installation position is only permitted
for the following modules:
• IM151-1 STANDARD: 6ES7 151-1AA02-0AB0
• PM-E 24 VDC: 6ES7 138-4CA00-0AA0
• 2DI 24 VDC Standard: 6ES7 131-4BB00-0AA0
• 2DI 24 VDC High Feature: 6ES7 131-4BB00-0AB0
• 4DI 24 VDC Standard: 6ES7 131-4BD00-0AA0
• 4DI 24 VDC High Feature: 6ES7 131-4BD00-0AB0
• 2DO 24 VDC/0.5 A Standard: 6ES7 132-4BB00-0AA0
• 2DO 24 VDC/0.5 A High Feature: 6ES7 132-4BB00-0AB0
• 4DO 24 VDC/0.5 A High Feature: 6ES7 132-4BD00-0AA0
• 2DO 24 VDC/2 A Standard: 6ES7 132-4BB30-0AA0
• 2DO 24 VDC/2 A High Feature: 6ES7 132-4BB30-0AB0
• 4DO 24 VDC/2 A Standard: 6ES7 132-4BD30-0AA0
• 2RO NO 24-120 VDC/5 A 24-230 VAC/5 A: 6ES7 132-4HB00-0AB0
Note
All of the supply and load voltages of the ET 200S must not exceed 24 VDC. This
voltage limit must be enforced.
