Dimension Drawings
B-7
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
66.5
135.5
3
67
Rail
support
202
15
Figure B-9 Dimensioned drawing of terminal modules (Fast Connect) with an electronic
module inserted
