7.2 Electromagnetic compatibility, shipping an d storage
conditions
Definition
Electromagnetic compatibility is the capability of an electrical device to function
satisfactorily in its electromagnetic environment without interfering with this
environment.
The ET 200S distributed I/O system also meets the requirements of the European
Union’s EMC legislation. A requirement for this is that the ET 200S distributed I/O
system meets the specifications and directives concerning electrical installation.
Pulse-shaped interference
The following table shows the electromagnetic compatibility of the ET 200S
distributed I/O system when confronted with pulse-shaped interference.
Pulse-shaped interference Tested with Corresponds to
severity
Electrostatic discharge
According to IEC 61000-4-2
8kV
kV
3 (air discharge)
2 (contact discharge)
Burst pulses (rapid, transient
interference) to
IEC 61000-4-4.
2 kV (power supply
line)
2 kV (signal line)
3
3
Surge to IEC 61000-4-5
Only with lightning conductors
(see the DP master manual and the SIMATIC NET PROFIBUS
Network description)
• Asymmetrical interconnection 2 kV (power supply
line)
2 kV (signal/data
line)
3
• Symmetrical interconnection 1 kV (power supply
line)
1 kV (signal/data
line)
