Remove/insertion interrupt by IM151-1 HIGH FEATURE
Byte x+4
Byte x+5
Byte x+6
76 054321
Byte x+7
Byte
x+8...
irrelevant
Type ID of the module; high byte
Type ID of the module; low byte
SKF-ID (STEP 7)
Legend: Type ID of a removed module: 8FC0
H
(empty slot)
Figure 6-34 Structure starting at byte x+4 for remove/insert interrupts
Byte x+4 to x+8 contains the ID of the module that has been removed or inserted.
The interrupt type in byte x+1 indicates whether the modules have been removed
or inserted (see Figure 6-27).
