Siemens SIMATIC ET 200S - TM-E15 S24-AT and TM-E15 C24-AT terminal module; (6 ES7 193-4 CLx0-0 AA0)

Terminal Module
9-26
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
9.10 TM-E15S24-AT and TM-E15C24-AT terminal module;
(6ES7 193-4CLx0-0AA0)
Order number
6ES7 193-4CL20-0AA0 (screw-type terminal)
6ES7 193-4CL30-0AA0 (spring terminal)
Properties
• Terminal module for electronic module 2AI TC High Feature
!
Caution
Only the 2AI TC High Feature electronic module can be attached to the
TM-E15S24-AT / TM-E15C24-AT terminal module. If a different electronic module
is attached, the internal reference junction of the terminal module may be
destroyed.
• The terminal module has an internal reference junction for temperature
compensation. This enables temperature compensation directly at the reference
junction of the thermal element.
• Connection with screw-type terminal with TM-E15S24-AT
• Connection with spring terminal with TM-E15C24-AT
• 2 x 2 terminals
• Basic wiring of the terminal module
• Build-as-you-go interference conductor from electronics module to standard
mounting rail over spring contact
• Inserting a shield connection element
• T raversing AUX1 rail without connection to terminals 4 and 8
