Siemens SIMATIC ET 200S - 2 DO 24 VDC;0.5 A Standard digital electronic module (6 ES7 132-4 BB00-0 AA0)

Digital Electronic Modules
11-47
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
Technical data
Dimensions and weight
Dimensions W x H x D (mm) 15 x 81 x 52
Weight Approx. 31 g
Module-specific data
Supports clock synchronized
mode
No
Number of inputs 2
Cable length
• Unshielded max. 600 m
(164 ft)
• shielded max. 1,000 m
(164 ft)
Voltages, currents, electrical potentials
Power supply (from the power
module)
230 VAC
• Frequency 47 to 63 Hz
Electrical isolation
• Between the channels No
• Between channels and
backplane bus
Yes
Permissible potential differ-
ence
• Between M
internal
and the
inputs
1500 VAC
Insolation tested with 4000 VDC
Power loss of the module Typical 0.7 W
Status, interrupts, diagnostics
Status display Green LED per
channel
Diagnostic functions No
Data for selecting a sensor
Input voltage
• Rated v alue
• for ”1” signal
• for ”0” signal
230 VAC
164 V to 264 V
AC
0Vto40VAC
Input current
• For signal ”1” 5to15mA
Input delay
• ”0” to ”1” transition 15 ms
• ”1” to ”0” transition 45 ms
Input characteristic curve To IEC 61131,
type 1
Connection of 2wire BEROs No
• permitted quiescent
current
max. 2 mA
11.11 2DO 24 VDC/0.5 A Standard digital electronic module
(6ES7 132-4BB00 -0AA0)
Order number
6ES7 132-4BB00-0AA0
Properties
• Digital electronic module with two outputs
• Output current 0.5 A per output
• A nominal load voltage of 24 V DC
• Suitable for solenoids, DC current protection and warning lights
