RESER VE modules
14-2
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
• Configure the interface module as follows:
Parameters Setting
Operation at Preset <> Actual
configuration
enabled
• If you have configured an electronic module with inputs for the RESER VE
module, the following substitute values are reported:
-- Digital Input Modules: 0
-- Analog Input Modules: 7FFF
H
-- Function Module: 0
Note
If you use the RESERVE module,
• the SF LED lights up on the interface module
• a channel-related diagnosis and module status ”10
B
: incorrect module” is
returned for that slot of the RESERVE module.
For the functioning and configuration with option handling see Chapter 3.8.
Terminal assignment
The RESERVE module is not connected to the terminals of the TM-E terminal
module. This means that the TM-E terminal module can be fully wired and
prepared for the future application.
Technical data
Dimensions and weight
Dimensions
WxHxD(mm)
Weight
15 x 81 x 52
30 x 81 x 52
approx. 33 g
(installation width
15 mm)
approx. 55g (installation
width30mm)
Voltages, currents, electrical potentials
Power loss of the
module
Typically 0.025 W
Status, Interrupts, Diagnostics
Status display No
Diagnostic functions No
