Vista 5 M3 Digital Mixing System
Parameters 3-11
Document generated: 28.08.13
SW V4.9
3.3.4 Mono AUXes
Press one of the GLOBAL VIEW: AUX MONO keys.
The mono AUX view provides selection of the AUX bus (ON/OFF), send
level adjustment, and pre-/after-fader switching. From 5.1 surround channels,
mono AUX sends are fed with an ITU-compatible mono down-mix.
AUX m x On/Off Mono AUX bus selection. Other mono AUX bus views can be selected as
well (5...8, 9...12, etc.).
AUX m x Rotary The send levels for mono AUX 1 through the maximum number configured
can be adjusted using this rotary encoder; adjustment range is from Mute (–∞)
through +10 dB.
AUX m x Pre/Post When the PRE / POST key in the fader bay’s GLOBAL VIEW area is active, the
Vistonics view changes as shown above at the right. The signal sent to the
mono AUX bus can be selected Pre (pre-fader, i.e. before the fader) or Post
(post-fader, i.e. after the fader).
