Vista 5 M3 Digital Mixing System
3-6 Parameters
Document generated: 28.08.13
SW V4.9
3.3 Global Views
3.3.1 Input
Press GLOBAL VIEW: INPUT GAIN.
For input sources IN 1, IN 2, and GEN (selection with the hardware keys
below the channel meters), an input control view is available. The number of
functions available on Input or Output channels, as well as on mono or stereo
channels, depends on the active configuration.
A DC reject filter is always active in each channel.
For input and output channels, the following parameters are available:
MONO INPUT STEREO INPUT MONO GROUP STEREO GROUP
MONO/STEREO
MASTER
MONO/STEREO
AUX
Parameters
IN1 IN2 GEN IN1 IN2 GEN IN1 IN2 GEN IN1 IN2 GEN IN1 IN2 GEN IN1 IN2 GEN
PHASE
X X X X X X X X X X X X – – – – – –
XY/MS-MODE
– – – X X – – – – X X – – – – – – –
INPUT MODE
– – – X X – – – – X X – – – – – – –
INPUT GAIN
X X X X X X X X X X X X – – – – – –
Mono Channel:
Stereo Channel:
