Studer Vista 5 M3 - Page 95

Vista 5 M3 Digital Mixing System
Parameters 3-7
Document generated: 28.08.13
SW V4.9
Input Parameters for Mono Channels only:
PHASE Two positions are provided (select either with the key or the rotary):
  • NORM/Off,inphase(defaultsetting).
  • REV/On,out-of-phase.
Input Parameters for Mono and Stereo Channels:
GAIN Input gain can set in 1 dB steps from –24 dB (attenuation by 24 dB) to +24 dB.
Default value: 0 dB.
In a stereo channel, left and right input gains are treated si multaneously.
Input Parameters for Stereo Channels only:
PHASE Four different positions are provided:
  • ++,inphase(defaultsetting).
  • –+,leftchannel(orinputA)out-of-phase.
  • +–,rightchannel(orinputB)out-of-phase.
  • ––,leftandrightchannels(orinputsAandB)out-of-phase.
Left
Right
Phase
Matrix
Stereo Channel
A
B
X
Y
Input Source
X = A
Y = B
+ +
:
X = –A
Y = –B
X = A
Y = –B
X = –A
Y = B
– +
:
+ –
:
– –
:
MS on/off Two different positions are provided:
  • MSoff(defaultsetting),forcoincidentXYstereomicrophonesetups.
  • MSon(Mid/Sideinformation),usedfordecodingMSinformationfrom
appropriate coincident stereo-microphone arrays.
2 CH MODE Five different positions are provided:
  • Stereo(defaultsetting).
  • Leftandrightsignalsareswapped.
  • Leftsignalonlyisroutedtobothleftandrightoutputs.
  • Rightsignalonlyisroutedtobothleftandrightoutputs.
  • Mono,leftandrightsignalmixedtogether(–3dB)androutedtobothleft
and right outputs.
Left
Right
Input
Mode
Matrix
Stereo Channel
A
B
X
Y
Input Source
Stereo:
X = A
Y = B
Mono:
Left:
Right:
Swapped:
X = (A+B)/1.414
Y = (A+B)/1.414
X = A
Y = A
X = B
Y = B
X = B
Y = A
If a channel contains the input balance function (configuration tool name
‘Input MS mode Bal Phase’), a balance control will be available in the pan
page. This balance control is actually set before the mono switch in the signal
path, within the input section of the channel. Hence it is possible to use the
