12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 235
Hardware Configuration Guide
SSU-2000 Configuration Chart
14. 3-Port SSU I/O Input
Adapter Panel
22013066-001-0
1. Use with 3-port DS1 or E1 Input Module.
2. Each port has DE9 and BNC connectors
(switch selectable) and selectable
termination (50, 75, 100, 120 or 3.3 k
Ω
).
3. Typically, 100 Ω termination for DS1
signals, 120 Ω for E1 signals, 50 and
75 Ω termination for 2,048 MHz or sine
wave signals.
4. Includes 1-m SCSI cable for connection
to SSU-2000.
15. 3-Port SSU I/O Input
Adapter Panel
22013066-002-0
1. Use with 3-port DS1 or E1 Input module.
2. Each port has DE9 and Siemens 1.6/
5.6 mm connectors (switch selectable)
and selectable termination (50, 75, 100,
120 or 3.3 kΩ).
3. Typically, 100 Ω termination for DS1
signals, 120 Ω for E1 signals, 50 and
75 Ω termination for 2,048 MHz or sine
wave signals.
4. Includes 1-m SCSI cable for connection
to SSU-2000.
16. 3-Port SSU I/O Input
Adapter Panel
22013066-003-0
1. Use with 3-port DS1 or E1 Input module.
2. Each port has DE9 and Siemens 1.0/
2.3 mm connectors (switch selectable)
and selectable termination (50, 75, 100,
120 or 3.3 kΩ).
3. Typically, 100 Ω termination for DS1
signals, 120 Ω for E1 signals, 50 and
75 Ω termination for 2,048 MHz or sine
wave signals.
4. Includes 1-m SCSI cable for connection
to SSU-2000.
17.
4-Port SSU I/O
Adapter Panel
22013069-001-0
1. One adapter panel serves up to four
1-port input modules.
2. Each port has DE9 and BNC
connectors (switch selectable) and
selectable termination (50, 75, 100, 120
or 3.3 kΩ).
3. Typically, 100 Ω termination for DS1
signals, 120 Ω for E1 signals, 50 and
75 Ω termination for 2,048 MHz or sine
wave signals.
4. Includes 1-m SCSI cable for connection
to SSU-2000.
Table 9-3. SSU-2000 System Components (Continued)
Item Description Part Number Notes
