Symmetricom SSU-2000 User Manual

Hardware Configuration Guide
SSU-2000 Configuration Chart
236 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
18. 4-Port SSU I/O Adapter
Panel
22013069-002-0 1. One adapter panel serves up to four
1-port Input modules.
2. Each port has DE9 and Siemens 1.6/
5.6 mm connectors (switch selectable)
and selectable termination (50, 75, 100,
120 or 3.3 kΩ).
3. Typically, 100 Ω termination for DS1
signals; 120 Ω for E1 signals; 50 and
75 Ω termination for 2,048 MHz or sine
wave signals.
4. Includes SCSI cable for connection to
SSU-2000.
19. 4-Port SSU I/O Adapter
Panel
22013069-003-0 1. One adapter panel serves up to four
1-port Input modules.
2. Each port has DE9 and Siemens 1.0/
2.3 mm connectors (switch selectable)
and selectable termination (50, 75, 100,
120 or 3.3 kΩ).
3. Typically, 100 Ω termination for DS1
signals; 120 Ω for E1 signals; 50 and
75 Ω termination for 2,048 MHz or sine
wave signals.
4. Includes SCSI cable for connection to
SSU-2000.
20. SCSI Cable, 1 m 805SCSI-0050 Connects I/O Adapter to rear panel of the
shelf.
Output Module, Output I/O Adapter Panels and Output Cables
21. E1 Output Module 23413018-000-0 1. Minimum of one Output module of any
type required.
2. Each Output module provides 20 single
output signals or 20 redundant signals
(if desired) in even/odd slots.
3. Each Output module or redundant pair
requires one Output I/O adapter panel.
4. Each two redundant Output modules
require one Output Summer connector
(part number 22013070-000-0) .
Table 9-3. SSU-2000 System Components (Continued)
Item Description Part Number Notes
