12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 239
Hardware Configuration Guide
SSU-2000 Configuration Chart
SDU-2000 Expansion Shelf
33. SDU-2000
Synchronization
Distribution Unit
Expansion Shelf,
comes with D-clock
cable
25413023-000-0 1. Up to 4 expansion shelves can be
attached to one SSU-2000 main shelf.
2. Requires minimum of 1 Buffer module
(2 recommended) and up to 14 Output
modules (no Input modules).
3. Output modules interchangeable
between Expansion shelf and Main shelf.
4. Last Expansion shelf requires SDU
termination plug (shipped with Main
shelf).
34. Buffer Module 25413022-000-0 1 or 2 required per SDU-2000 expansion
shelf (install in slots A15 and A16).
Blank Filler Panels
35. Clock Module Filler
Panel (3.2 in. wide)
10913022-000-0 Filler panels are required in all unused clock
slots.
36. Standard Module Filler
Panel (1 in. wide)
10913021-000-0
Filler panels are required in all unused
SSU-2000 and SDU-2000 I/O slots.The
1-inch panel fits all unused slots in an
Expansion shelf and all except A1 and A12
(two end slots) in the Main shelf.
EIA-232 Cable
37.
Cable, EIA-232 Shielded,
DB9P to DB9S, 5 ft.
(1.5 m)
551026-0038 Used for communication with the
SSU-2000.
Table 9-3. SSU-2000 System Components (Continued)
Item Description Part Number Notes
