TL1 Command Interface
290 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
RTRV-PRMTR-CCOUT:[tid]:[aid]:
ctag;
Valid aid code: ALL, SxAy[-z]
This command returns the settings for the composite clock
port designated by the
aid. If a port is specified in the
request, the format for each response message line is:
^^^"aid:mode,level,bypass,pstate,duty,pcomp"<cr lf>
where:
aid = port access identifier
mode = CC (composite clock)
level = minimum clock level to enable outputs on the
module [WARM|ACQ|LOCK]
bypass = allows Clock C selection: [ON|OFF]
pstate = port state [ON|OFF]
duty = duty cycle of the modules outputs [1|0] where 1 =
5/8 and 0 = 50/50
pcomp = phase compensation [1 through 7]
When no port is specified by the
aid, then the response is
four lines as follows:
^^^"aid: mode,level,bypass"<cr lf>
^^^"aid:pstate1,pstate2,pstate3,…pstate20”<cr lf>
^^^"aid:duty1,duty2,duty3,…duty20”<cr lf>
^^^"aid:pcomp1,pcomp2,pcomp3,…,pcomp20”<cr lf>
Line 1 contains:
aid = module access identifier
mode = CC
level = minimum clock level to enable outputs on the
module [WARM|ACQ|LOCK]
bypass = allow Clock C selection: [ON|OFF]
Line 2 contains:
aid = module access identifier
pstate# port state [1| 0] (1 = ON, 0 = OFF), where # =
port number 1 through 20
Line 3 contains:
aid = module access identifier
duty# = duty cycle of the module outputs [1|0], where: 1
= 5/8, 0 = 50/50
# = port number 1 through 20
Line 4 contains:
aid = module access identifier
pcomp# = phase compensation 1 through 7
# = port number 1 through 20
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
