TL1 Command Interface
292 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
RTRV-PRMTR-CLKOUT:[tid]:[aid]:
ctag;
Valid aid code: ALL, SxAy[-z]
This command returns the output port setting when a port
aid is specified.
The format for the response message is:
^^^"aid:mode,level,bypass,fltmode,pstate,
squelch” <cr lf>
where:
aid = module access identifier
mode = CLK
level = [WARM|ACQ|LOCK] for the clock level where
outputs are turned on,
bypass = allow Clock C selection: [ON|OFF]
fltmode = determines if outputs are set to fault [OFF|
ON|AUTO] when signal levels drop below the threshold
output level
pstate = port state [1|0] (where 1 = ON and 0 = OFF).
squelch = threshold value [0|1|...|16] (where 0 =
disabled). If the reference clock PQL exceeds this value,
then the output is turned off.
When no port is specified by the aid, then the response is
two lines as follows:
^^^"aid:mode,level,bypass,fltmode” <cr lf>
^^^"aid:pstate1,pstate2,…,pstate20” <cr lf>
^^^"aid:squelch1,squelch2,…,squelch20” <cr lf>
where:
Line 1 contains:
mode = CLK
level = [WARM|ACQ|LOCK] for the clock level where
outputs are turned on,
bypass = [ON|OFF] for allowing Clock C selection
fltmode = determines if outputs are set to fault [OFF|
ON|AUTO] when signal levels drop below the threshold
output level
Line 2 contains:
aid = access identifier of module
pstate# = port state [1|0] 1 = ON and 0 = OFF, and # =
port number 1 through 20
Line 3 contains:
aid = access identifier of module
squelch# = squelch value [0|1...|16] and # = port number
1 through 20
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
