12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 297
TL1 Command Interface
RTRV-PRMTR-OUTE12048:[tid]:
[aid]:ctag;
Valid aid code: ALL, SxA[y[-z]]
This command returns the settings for the port specified by
the aid. The format for each response message line is:
^^^"aid:mode,bypass,zs,signal,pstate, squelch"
<cr lf>
where:
aid = aid for the module
mode = CAS
bypass = [ON|OFF] for allowing Clock C selection
zs (zero suppression) = [ON|OFF]
signal = port signal type [E1|2048]
pstate = port enabled state [ON|OFF
squelch = PQL threshold value [0|1|2|...|16]; when a
reference clock PQL value exceeds this threshold, then
the port output is disabled. Zero indicates the function is
disabled.
When the aid does not specify a port, the response is:
^^^"aid:mode,bypass,zs"<cr lf>
^^^"aid:signal1,signal2,...signal20"<cr lf>
^^^"aid:pstate1,pstate2,...pstate20"<cr lf>
^^^"aid:squelch1,squelch2,...squelch20" <cr lf>
where:
Line 1 contains:
aid = aid for the module
mode = CAS
bypass = [ON|OFF] for allowing Clock C selection
zs = zero suppression: [OFF|ON]
Line 2 contains:
aid = aid for the module
signal# = signal type [0|1] (0 is 2048, 1 is E1) and # is
the port number 1 through 20
Line 3 contains:
aid = aid for the module
pstate# = port enabled state [0|1] (0 is Off, 1 is On) and
# is the port number 1 through 20
Line 4 contains:
aid = aid for the module
squelch# = squelch value [0|1|...|16] and # is the port
number 1 through 20
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
