TL1 Command Interface
298 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
RTRV-PRMTR-OUTPUT:[tid]:[aid]
:ctag;
Valid aid code:
ALL, SxA[y[-z]]
Returns the output port setting when a port aid is specified.
The format for the response message is:
^^^"aid:mode,level,bypass,zs,crc,bit,pstate,len"
<cr lf>
where:
aid = aid of the port
mode = output signal mode [ESF|D4|CCS|CAS]
level = [WARM|ACQ|LOCK] for the clock level where
outputs are turned on
bypass = allow Clock C selection [ON|OFF]
zs = zero suppression
crc = error checking crc are [ON|OFF]
bit = SSM bit [4 through 8] for E1 sync status messages
pstate = port enabled state [ON|OFF]
len = line length setting of [133|266|399|533|655] for
DS1 outputs
When the aid does not specify a port, the response is:
^^^"aid:mode,level,bypass,zs,crc,bit
"
<cr lf>
^^^"aid:pstate1,pstate2,…pstate20
"
<cr lf>
^^^"aid:len1,len2,len3,…,len20
"
<cr lf>
Line 1 contains:
aid = module access identifier
mode = outputs signal mode: [ESF|D4|CCS|CAS]
level = clock level: [WARM|ACQ|LOCK] when outputs
are turned on
bypass = allow Clock C selection: [ON|OFF]
zs = zero suppression: [ON|OFF]
crc = error checking: [ON|OFF]
bit = SSM bit [4 through 8] for E1 sync status messages
Line 2 contains:
aid = port access identifier
pstate# = port enabled state [1|0] (1 = ON and 0 = OFF)
and
# is the port number 1 through 20
Line 3 contains:
aid = access identifier of the port
len# = line length setting of [133|266|399|533|655] for all
20 DS1 output ports and
# is the port number 1 through
20
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
