12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 299
TL1 Command Interface
RTRV-PRMTR-PBO:[tid]::ctag;
Valid aid code: none
This command returns the Phase Build-Out (PBO) settings
for the system. All input modules will use this setting. The
format for each response message line is:
^^^"aid:pbo_mode" <cr lf>
where this aid is specified as ALL (i.e. all DS1/E1 input
modules). The
pbo_mode is [DIS| EVT| REP| NONE].
DIS indicates the PBO function has been disabled.
EVT indicates the PBO function is enabled. PBO events
are displayed and stored in the COMM module event
buffer.
REP indicates the PBO function is enabled.
PBO events are displayed, but the event is not stored in
the COMM module event buffer.
NONE indicates the PBO function is enabled. The PBO
event is neither displayed nor stored in the COMM
module event buffer.
RTRV-PRMTR-SNMP-MODE:[tid]::
ctag;
Valid aid code: none
This command returns the current SNMP mode. The format
for each response message line is:
^^^"mode,trap_filter" <cr lf>
Values for mode are as follows:
ENA Enables SNMP operation in the system
DIS Disables SNMP operation in the system
Values for trap_filter are as follows:
ALM Only alarms cause Traps to be transmitted
ALL All events and alarms cause the transmission of
Traps
RTRV-PRMTR-SNMP-USER:[tid]::cta
g;
Valid aid code: none
This command returns the current SNMP user list. The
format for each response message line is:
^^^"read_community,level" <cr lf>
Where read_community is the assigned Read Community
String used by SNMP and
level is the access level
assigned to that user. No Write Community String is
displayed. This is only accessible by Level 4 users.
RTRV-PRMTR-SNMP-MANAGER:[tid]
::ctag;
Valid aid code: none
This command returns the SNMP Manager list. The format
for each response message line is:
^^^"ip_address" <cr lf>
where: ip_address is the assigned SNMP Manager IP
address
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
To Next Page
