097-55501-02 Issue 7 – January, 2005 TimeHub 5500 TL1 Reference Guide 155
Performance Monitoring
Measurements
Table 4-3 lists LMRTIE measurements and the measurement time period for an
input port.
Command Example:
RTRV-PM::CLK-4:SC1::LMRTIE;
The response to the command in this example displays LMRTIE information about
input port 4.
Parameter Value Description
CLK a-b a = 1 or 2 Clock card from which data was collected
b = 1 to 4 Input port number of Clock card from which data was
collected
LMRTIE-a a = 1S, 1M, 15M, 30M, 1H,
2H, 8H, 24H
Performance monitoring measurement type, where a is the
observation time interval (refer to Table 4-3 for details).
Variable a can also be appended to LMRTIE in RTRV-PM
to obtain a response for only that measurement time
<monval> Calculated values for maximum phase variation of the input signal in nanoseconds
<status> COMPL Observation time calculation was completed
NA,NA Observation time calculation is not yet available
<meas time> Measurement time in which data was collected. Once the measurement time reaches
24 h, data older than 24 h are lost as new data are collected.
Table 4-3 LMRTIE Measurements and Time Periods for Single Input Port
Measurement
Observation Time
First Data
Available After
Updated Every
Includes Data
from Last
LMRTIE-1S 1 s 1 s 1 s
LMRTIE-1M 1 min 1 min 1 min
LMRTIE-15M 15 min 15 min 15 min
LMRTIE-30M 30 min 15 min 30 min
LMRTIE-1H 1 h 15 min 1 h
LMRTIE-2H 2 h 15 min 2 h
LMRTIE-8H 8 h 15 min 8 h
LMRTIE-24H 24 h 15 min 24 h
