097-55501-02 Issue 7 – January, 2005 TimeHub 5500 TL1 Reference Guide 163
Performance Monitoring
Measurement Properties
Displaying
To display measurement properties for an input port, the command format is:
RTRV-[-TSG]:[<tid>]:<aid>:<ctag>:::PARAMETER=<mo ...>SYNC;
Table 4-7 Measurement Properties
Measurement
Property
Measurement Description
Factory
Setting
THR Threshold value, in nanoseconds, for TDEV
monitored type
0
Threshold value, in nanoseconds, for MRTIE
monitored type
0
Threshold value, in nanoseconds, for LMRTIE
monitored type
0
Threshold value, in ppm, for SPRD monitored
type
0
Threshold value, in ppm, for FFOFF
monitored type
0
CRI Indicates if an input port is qualified (Y) or
disqualified (N). Does not apply to SPRD or
FFOFF monitored types
N
RPT Indicates if an event is generated (Y) or not
generated (N) when a threshold is crossed
N
PM Automatically displays (Y) or does not
automatically display (N) each new
measurement as it occurs
N
GOOD Number of consecutive good measurements
that must occur following a bad measurement
before an input signal can be qualified and for
the INMEAS event to be cleared
1
Parameter Value Variables Description
<aid> CLK-a a = 1 to 4 Input port number of Clock card. Applies to
monitored types other than SPRD.
CLK — All input ports of Clock card. Applies to SPRD
monitored type only.
