Symmetricom TimeHub 5500 Reference Guide

097-55501-02 Issue 7 – January, 2005 TimeHub 5500 TL1 Reference Guide 91
Keywords
Overview
MANCHAN
(Manual Channel)
0 0 - 4 ED-EQPT::CLK:SC39:::
MANCHAN=1;
MEASDLY
(Measurement Delay)
0 0 - 1800 ED-SYNC::CLK-3:SC40:::
MEASDLY=20;
MONITOR
(Input Event Monitoring)
Y (Inputs 1-4)
N (Inputs 4-8)
Y / N ED-SYNC::CLK-4:SC41:::
MONITOR=N;
OMANSSM
(Output Manual SSM)
N Y / N ED-EQPT::S0-OUTA:SC43:::
OMANSSM=Y;
OQLEVEL
(Output Quality Level)
9 1 - 9 ED-EQPT::OUTB:SC44:::
OQLEVEL=9;
OUTESF
(Output ESF)
Clock firmware
prior to version
4236B: N
Clock firmware
version 4236B or
later: Y
Y / N ED-EQPT::S1-OUTA-PG1:SC45:::
OUTESF=Y;
PIRANGE
(Pull-In Range)
16 10 - 10000 RTRV-EQPT::CLK:SC46:::
PARAMETER=PIRANGE;
PIRANGESEC
(Pull-In Range for
Secondary Oscillator)
4600 10 - 10000 RTRV-EQPT::CLK:SC47:::
PARAMETER=PIRANGESEC;
PORTAO
(Event Reporting Port
Number–Working Memory)
7589 -- RTRV-EQPT::IMC:SC48:::
PARAMETER=PORTAO;
PORTAOX
(Event Reporting Port
Number–Auxiliary Memory)
7589 5001 - 20000 ED-EQPT::IMC:SC49:::
PORTAOX=5003;
PORTCMDS
(Command/Response
Reporting Port
Number–Working Memory)
7588 -- RTRV-EQPT::IMC:SC52:::
PARAMETER=PORTCMDS;
PORTCMDSX
(Command/Response
Reporting Port
Number–Auxiliary Memory)
7588 5001 - 20000 ED-EQPT::IMC:SC53:::
PORTCMDSX=5002;
PRC5MHZ
(PRC 5MHz Signal)
N Y / N ED-SYNC::CLK-0:SC54:::
PRC5MHZ=Y;
Table 3-1. Keywords and Descriptions (Continued)
Keyword/
Description
Default
Value
Accepted
Value
Example Command
