1.2.4 LED signals
1.2.4.1 Overview
SOMANET Circulo has several LEDs that show the drive’s state or indicate errors.
1.2.4.1.1 Legend
Symbol Explanation
Off
Constantly luminous
Single flashes (1 pulse per second)
Slow blinking (3 pulses per second)
Fast blinking (10 pulses per second)
Two colored behavior: One part of the
LED is constantly luminous, the other is
blinking slowly (3 pulses per second)
