3.1.9.1.127 0x6072 Max torque
The configured maximum permissible torque in the motor. The value is given in per thousandth of rated
torque.
Max Torque = τmax_Datasheet τrated_Datasheet × 1000
For example, if the rated torque from the datasheet is 200 Nm and maximum torque is 600 Nm,
Max Torque = 600 Nm 200 Nm × 1000 = 3000
Name Index:Sub Type Bit
Size
Min
Data
Max
Data
Default
Data
Unit Access PDO
Mapping
Max torque 0x6072:0 UINT 16 0 32767 3000 readwrite Receive
PDO
(Outputs)
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 770/887
