SYNAPTICON CIRCULO 7 User Manual

Attention
In case of multiple drive connection, ensure that the output driver has sufficient current driving
capability.
1.3.2.6.3.2 Connection diagram for the brake
Attention
Phase D can’t be used for connecting a brake when Node Safety is used:
use the safety brake connector of the safety circuit (SBC out) instead of phase D of the drive circuit.
ensure to connect the brake GND signal to the Brake- signal of the safety circuit (SBC out) instead of
the general GND.
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 270/887
