Pin Signal Direction / Comment
1 MA- Input
2 +5V Input
3 GND 5V Return
4 MA+ Input
5 SLO- Output
6 SLO+ Output
1.4.4.4 Mounting remarks
The PCB can be shrinked to a shrink tube with a diameter of 20 mm.
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 306/887
