SYNAPTICON CIRCULO 7 - Manual Switch + Drives; Safety PLC PM (Plus-Minus Output) + Drives

1.2.5.3.2.1 Manual switch + drives
Allows safety functions up to SIL 3, PL e, cat.3.
1.2.5.3.2.2 Safety PLC PM (Plus-Minus output) + drives
Allows safety functions up to SIL 3, PL e, cat.3.
Note
Safety GND functions as a secondary line when a PLC with Plus-Minus output is used.
Attention
In case of multiple drive connection, ensure that the output driver has sufficient current driving
capability.
