SYNAPTICON CIRCULO 7 User Manual

3.1.3.2.3 Limitations
Please note that the brake phase voltage control comes with limited accuracy.
Use this feature only in low precision applications (e.g. load-dependant speed of a fan).
3.1.3.2.3.1 Parameters related to Controlling the brake output voltage
0x2004 Brake Release Release strategy can be used to activate the voltage on the brake output, Brake
options: Brake status turns it On and Off, Brake options: Output voltage sets the voltage.
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 392/887
