1.4.3 Industrial I/O Cable Adapter
1.4.3.1 Overview
The Industrial I/O Cable Adapter is a compact module converting LVTTL (3.3 V) logic level IOs into standard
industrial isolated 24 V I/Os. It converts 4 GPIOs to two digital inputs and outputs. The main purpose of the
adapter is to enable connection of 24 V I/O industrial devices to SOMANET servo drives.
