3.1.4.1 Analog In
Analog sensors usually output a voltage or a resistance that can be interpreted by the firmware. When the
output is a voltage, the signal can be directly read by the analog input, but if it’s a resistance (e.g. resistance
temperature detectors), a voltage divider must be used to generate a voltage equivalent to the resistance.
Important
If your servo drive does not incorporate a voltage divider itself, you must attach one separately.
SOMANET servo drives come with a default configuration for the analog inputs that can be alternated on
request.
For details please refer to SOMANET Node’s Analog In configuration or to SOMANET Circulo’s Analog In
configuration .
3.1.4.1.1 Using differential inputs for single-ended sensors
If you want to attach a single-ended encoder but the voltage range fits only to the differential ports, you may
connect the signal to the + pin of the Analog In and the Ground to the - pin.
Note
In this case you will lose half of your analog input range.
3.1.4.1.2 Nonlinear conversion of an analog voltage
External scaled measurement: Nonlinear conversion of an analog voltage using a 5th order polynomial
function.
