1.3.2.1 Technical Specifications
1.3.2.1.1 Power Specifications
Power Specifications
Node Size Node 400 Node 1000 Node 2000
Maximum Peak Output Power 415 W 1,040 W 2,080 W
Maximum Continuous Output Power * 415 W 1,040 W 1,200 W
Nominal Supply Voltage ** 12-48 V DC
Maximum Supply Voltage ** 60 V DC
Minimum Supply Voltage ** 10 V DC
Maximum Input Current DC 9.6 A DC 24 A DC 48 A DC
Maximum Phase Current RMS 13.2 A RMS 33 A RMS 66 A RMS ****
Maximum Continuous Phase Current RMS * 13.2 A RMS 33 A RMS 36 A RMS
Efficiency (at Maximum Power) 98 %
Brake control power output 0-48 V PWM Phase D ***
* Information about the maximum values can be found below.
** The operating voltage is 12-48 V DC. The maximum supply voltage is only for buffering peaks when braking.
The minimum voltage is for configuration purposes only. Please refer to our power supply instructions for
details.
*** This is a fourth phase that can also be used for other purposes (see Manually controlling phase D voltage) it
has a maximum current of 10 A.
**** Details for the Maximum Continuous Phase Current and the Load cycles can be found below
