3.1.3.3.1.2 Selecting the PWM frequency of the brake
The PWM frequency of the brake can be changed in object 0x2004:11 Brake options: Switching frequency.
Enter the value 0 for 16 kHz
Enter the value 1 for 32 kHz
Enter the value 2 for 64 kHz
3.1.3.3.1.3 Custom brake modes
It is also possible to implement custom brake modes. For information please refer to Manually controlling
phase D voltage
3.1.3.3.1.4 Parameters related to the Brake
0x2004 Brake Release All options that are required for brake release.
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 396/887
