Output short circuit current typ. < 1 A

[1]

With attached strain relief.

1.4.3.3 Pinouts

1.4.3.4 Connector details and mating parts

J1 Conector

Manufacturer JST

Part number SM08B-GHS-TB(LF)(SN)

Conductor cross section AWG min. 30

Conductor cross section AWG max. 26

Mating part for Housing GHR-08V-S

Crimping Contact SSHL-002T-P0.2

J2 and J3 Connectors
