1.4.2.5 Strain relief
The board will be delivered with a strain relief. A cable tie can be used as a strain reliever:
On the right side of the image, the cable tie is symbolized in red and the cables in black. The Synapticon Logo
can be connected to PE, e.g. the shield of a cable. There is the possibility to place a CAP and a resistor between
PE and GND. In Standard version this is not placed.
If not needed, the strain reliever part can be broken off, then the module is shorter.
1.4.2.6 Soldered cables
Cables can also directly be soldered to the PCB. If this option is needed, please contact sales@synapticon.com
