1.3.2.6.3.2.1 Brake power output (STO/SBC)
Pin # Designation Function
1 + Brake +
2 - Brake -
Note
The safe brake is PWM based and can be configured with the regular brake object.
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 271/887
