1.2.6.2.1.2.3.3 Using the external encoder 2 and the internal encoder 2 at the same
time
Since firmware 4.4 it is possible to use the external encoder 2 and the internal encoder 2 at the same time.
Attention
Simultaneously, the integrated encoder 2 and the external encoder 2 can only be used with HALL or ABI
(Single-Ended or Differential but not Fast ABI).
1.2.6.2.1.2.4 Digital IO
Circulo 7
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 159/887
