Circulo 7
Circulo 9
Note
The values in the image are optimal values, if needed the maximum values in the table below “Mounting
tolerances” can be used.
Attention
Before they can be used, the encoders need to be calibrated
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 184/887
