SYNAPTICON CIRCULO 7 User Manual

OpnTermC Open Terminal
C
Drive terminal C is opened.
This error can happen if
motor cable is not
connected to terminal C of
the Drive. It can also
happen if the Drive is
damaged internally..
Open FET Faults
OpnFetAH Open high FET
at phase A
One of the power
electronic switches of
Drive is damaged (not
conducting). The damaged
FET is located in leg A of
the inverter, and it is the
high-side FET of this leg.
Please note down the information regarding
the occurence of the error and reach
Synapticon technical support for further
investigation.
OpnFetBH Open high FET
at phase B
One of the power
electronic switches of
Drive is damaged (not
conducting). The damaged
FET is located in leg B of
the inverter, and it is the
high-side FET of this leg.
OpnFetCH Open high FET
at phase C
One of the power
electronic switches of
Drive is damaged (not
conducting). The damaged
FET is located in leg C of
the inverter, and it is the
high-side FET of this leg.
OpnFetAL Open low FET
at phase A
One of the power
electronic switches of
Drive is damaged (not
conducting). The damaged
FET is located in leg A of
the inverter, and it is the
low-side FET of this leg.
OpnFetBL Open low FET
at phase B
One of the power
electronic switches of
Drive is damaged (not
conducting). The damaged
FET is located in leg B of
the inverter, and it is the
low-side FET of this leg.
Synapticon Documentation
© 2021 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.11.0 | Built 2021-07-23 665/887
