Select desired number of pulses in one sinewave.
This value is going to be used to calculate the singleturn resolution (Resolution).
Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
Sinusoidal
output
voltage
0x220E:8 USINT 8
up to 50 mVpp 15
up to 60 mVpp 14
up to 75 mVpp 13
up to 0.1 Vpp 12
up to 0.12 Vpp 11
up to 0.14 Vpp 10
up to 0.15 Vpp 9
up to 0.2 Vpp 8
up to 0.28 Vpp 7
up to 0.4 Vpp 6
up to 0.5 Vpp 5
up to 0.6 Vpp 4
up to 0.75 Vpp 3
up to 1 Vpp 2
up to 1.2 Vpp 1
up to 1.5 Vpp 0
readwrite
Differential voltage in the Sin/Cos outputs peak to peak.
It is often abreviated as Vpp.
Name Index:Sub Type Bit
Size
Options Unit Access PDO
Mapping
Index
availability
0x220E:9 BOOL 1
Encoder without
index
0
Encoder with index 1
readwrite
Define if the connected encoder has an index or not.
The index is often called "reference".
