Bus setups Label a bus

Here is an example of a setup for an SPI bus with a label.

Behavior

The bus label appears in the list of bus setups in the Conﬁg and Display tabs. The instrument also displays

the label adjacent to the bus number on the screen for easy identiﬁcation.

What do you want to do next?

Learn more about bus setups. (see page 95)

Lea

rn about bus conﬁguration.

(see page 148)

Learn about digital setups. (see page 87)
