Tektronix DPO5000 Series User Manual

Bus setups Opening a bus symbol table file
Behavior
This dialog box opens to the default directory C:\Users\[Username]\Tektron ix\TekScope\Bus-
DecodeTables
. If you saved the file in another directory, you need to copy the file to the
C:\Users\[Username]\Tektronix\TekScope\BusDecodeTables directory, where the instrument expects to
find it. When you open a symbol table file, the instrument uses the values to decode and display bus
values
to be easier to recognize.
NOTE. Theonlyavailablefile is in TSF format.
What
do you want to do next?
Learn about bus symbol tables. (see page 153)
Learn about the format. (see page 154)
See an example of parallel bus values displayed as symbols. (see page 592)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 157
