Mask testing setups Set up mask test fail notiﬁcation

SRQ. When SRQ is turned on, the instrument sends a GPIB SRQ command when a mask test fails.

AUX Out. When AUX Out is turned on, the instrument sends a trigger to the Auxiliary Out connector

when a mask test fails. See External Signals Control Window

(see page 546) for additional details

on this feature.

What do you want to do next?

Learn about mask polarity. (see page 227)

Learn about waveform parameters. (see page 224)

Go to the Test Setup control window. (see page 221)
