Math setups Math equation editor (Filter tab)

6. Edit the math expression using the Operands and edit controls if needed.

7. When you ﬁnish building the expression, click Apply.

Behavior

You can use any of the channels as arguments for the function. Create nested functions by inserting

a function into the argument portion of another.

What do you want to do next?

Learn about the Spectral Setup controls. (see page 246)

Learn about using math functions with math waveforms. (see page 259)

Learn

about using the Measurement list with math waveforms.

(see page 264)
