Trigger setups Set up an Ethernet bus trigger
In this example, you need to set the Source Port, Destination Port, Seq Number, and set the Acq Number.
Click the Trigger On selections Start Frame Delimiter (see page 416), MAC Addresses (see
page 417),Q-Tag Control Information (see page 417) ,MAC L ength/Type (see page 417) ,IPv4 Header (see
page 418) , TCP/IPv4 Client Data (see page 418),MAC Data (see page 419) ,End of Packet (see page 419)
, Idle (see page 419),orFCS (CRC) Error (see page 420) to view their parameters.
What do you want to do next?
Learn about bus setups. (see page 95)
Trigger on Start Frame Delimiter
Select Start Frame Delimiter to trigger on an Ethernet Start Frame Delimiter.
416 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
