Oscilloscope Reference Set horizontal delay and horizontal position
Horizontal/Acquisition control window ( Acquisition tab)
From the Horiz /Acq menu, select Horizontal/Acquisition Setup; then open the Acquisition tab.
Overview
Use the Acquisition tab to set the acquisition parameters for all live waveforms. The Acquisition
controls are common to all channels. This means that you cannot acquire in Sample mode on channel
1 while chan
nel 2 acquires in Envelope mode.
For information on the controls, click on the buttons.
Acquisition Mode (see page 836)
Fast Acquisitions (see page 186)
Roll Mode (see page 188)
Sampling Modes (see page 189)
FastFra
me Control Windows
(see page 195)
External Signals Control Window (see page 546)
Behavior
Acqui
sition is the process of sampling the analog input signal, d igitizing the signal to convert it into
digital data, and then assembling the signal information into a waveform record. The instrument
creates a digital representation of the input signal by sampling the voltage level of the signal at
regular time intervals. The sampled and digitized points are stored in memory along with the
corresponding timing information. The instrument uses the digital representation o f the signal for
display, measurements, or for further p rocessing.
Use the controls on this tab to define the sampling method, the acquisition mode, turn Fast
Acquisitions on or off, and activate an external reference.
What do you want to do next?
Learn about Acquisition modes. (see page 836)
Set horizontal delay and horizontal position
From the Horiz /Acq menu, select Horizontal/Acquisition Setup; then open the Horizontal tab (see
page 177).
Overview
Use this control to select the amount of data that a ppears before the trigger event.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 839
