Oscilloscope Reference Set the setup and hold times
Set the setup and hold times
Use the Setup Time and the Hold Time controls to specify the setup and hold limits.
1. Click in a data entry box.
2. Use the multipurpose knobs to set the limits.
Enter a spectral math equation
From the Math menu, select Equation Editor, or click the Editor button in the Math Setup or Spectral
Setup control windows.
To use
Select a Math <1-4> waveform from the drop-down list.
Clickinthereadoutfieldtoenterthemathexpression.
Click a button to enter its character or operator into the expression.
Click the Editor (see page 257) button and use the Math Equation Editor controls to insert numerals,
math operators, and variables into a math expression.
Use the Text Edit Controls (see page 259) to move the insertion point (cursor) within the expression.
Behavior
These controls only a ffect the selected math waveform.
What do you want to do next?
Learn about the Equation Editor. (see page 257)
Enter a spectral math expression
From the Math menu, select Advanced Spectral, or click Advanced in the Math Setup control w indow;
then open the Create/Edit tab.
To use
Use these controls to insert spectral analysis functions into the math expression.
1. Click one of the buttons to insert a function into the math expression.
916 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
