Oscilloscope Reference Specify the video trigger holdoff
Specify the video trigger holdoff
1. Click in the Holdoff field.
2. Specify Holdoff By Time or By Fields.
3. Use the multipurpose knob to change the value.
If you are setting a Custom format, only the By Time control is available.
Select the
video trigger polarity
Select ei
ther Normal or Inverted polarity.
Normal. This polarity generally triggers on the negative polarity, since the sync pulse leading edge is
negativ
e for most standard formats.
Inverted. Use this polarity when probing circuitry that inverts the video signal.
VXI 11.2 LAN server
The VXI 11.2 LAN Server provides software connectivity between your instrument and remote PCs over
an Ethernet LAN. This tool is a client-side component built-in with TekVISA on each remote PC, you
must i
nstall another copy of TekVISA to make use of its client-side component.
TheVXI-11standardspecifies a protocol for communication with devices o ver a network via a network
inst
rument server. This protocol uses the ONC/RPC (Open Network Computing/Remote Procedure
Call) standard that, in turn, is based on TCP/IP.
960 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
