ProcedureforGearPumpFlowTest(continued)
FRONT
RIGHT
3
2
1
4
X
g287816
Figure74
1.1
st
pumpsectionhose3.2
nd
pumpsectionhose
2.LeftdeckmanifoldP14.FrontdeckmanifoldP1
2.Determinewhichgearpumpsectionistobetested.Thoroughlycleanand
thendisconnecthydraulichosefromappropriatemanifoldttingforgear
pumpsectionthatistobetested:
A.For1
st
gearpumpsection(sidedeckow),disconnecthydraulichose
fromttinginleftdeckmanifoldportP1(Figure74).
B.For2
nd
gearpumpsection(frontdeckow),disconnecthydraulichose
fromttinginfrontdeckmanifoldportP1(Figure74).
C.For3
rd
gearpumpsection(steering,lift/lowerandtractionchargecircuits),
raisehoodanddisconnecthydraulichosefromttinginsteering/decklift
manifoldportP1(Figure75).
1
2
3
FRONT
g287817
Figure75
1.3rdpumpsectionhose
3.ManifoldP1port
2.Steering/liftmanifold
Groundsmaster
®
5900&5910
Page5–69
HydraulicSystem:Testing
16227SLRevB
